APC Rack PDU 2G, Switched, 30A, 200/208V, (21) C13 & (3) C19 Power Distribution Unit

The APC AP8941 is a rack power distribution unit from APC’s second generation line that delivers power rated at 200 to 208 volts and 30 amps to demanding IT equipment while giving staff full, outlet-level control.

With twenty-one C13 and three C19 outlets arranged along a vertical housing, the unit supports servers, network switches, and storage arrays in the same rack. Each outlet can be switched on its own, so a technician can reboot a locked server or cut power to unused gear without leaving the desk. Access is available through a secure web interface, SNMP, or a command-line session, making it easy to integrate the PDU into an existing monitoring platform.

An embedded memory log captures volts, amps, and kilowatt hours for every phase, which helps teams track real-time load trends, plan capacity, and document energy use. User-defined alarms alert you when current or temperature approaches safe limits, giving you time to act before service is affected.

The housing mounts in the zero U space at the side of the rack, so no equipment space is lost. A ten-foot line cord with a NEMA L6-30P plug reaches distant receptacles, and tool-less brackets clip directly into APC NetShelter mounting channels. Once in place, a rugged frame and internal overload protection defend against accidental damage and unexpected surges.

An auxiliary port accepts an optional temperature or humidity sensor, providing instant insight into environmental conditions at the rack level. The combination of outlet-level switching, detailed metering, and environmental awareness makes the AP8941 a practical choice for data centers, edge sites, and lab benches where uptime and efficiency matter.

• Twenty-one C13 and three C19 outlets power a range of rack-mounted equipment
• Individual outlet switching allows remote reboot and scheduled shutdown
• Vertical zero U mounting frees every rack unit for hardware
• Real-time load and energy meters with adjustable alarms
• Embedded memory log stores volts, amps, and kilowatt hours
• Input accepts 200 to 208 volt service at up to 30 amps
• Ten-foot cord with NEMA L6-30P plug simplifies connection to branch power
• Port for optional temperature or humidity sensor supports environmental monitoring
• Brackets install without tools in APC NetShelter racks
• Durable construction with built-in overload protection
